ST-4
USER MANUAL
17
~TFT DISPLAY SETUP
{ COLOR ADJUST
Using the Standard Navigation Mode, highlight the CROMA item and then set
the desired colour depth.
{ CONTRAST ADJUST
Using the Standard Navigation Mode, highlight the CONTRAST item and then
set the required contrast level.
{ BRIGHTNESS ADJUST
Using the Standard Navigation Mode, highlight the BRIGHTN. item and then set
the required brightness level.
{ NTSC COLOUR INTENSITY ADJUST
Using the Standard Navigation Mode, highlight the NTSC TINT. item, and then
set the required level.
{ VIDEO INPUT SELECTION
The TFT display [G] can be set to display the video signal from an external
source/device connected to the meter through the RCA connector [S3].
Using the Standard Navigation Mode, highlight the VIDEO IN item, and then
select INT (to display the signals coming from the meter built-in demodulator) or
EXT (to display the signals coming from an external device).
Press once and release the MEAS
[4] key to quit this menu.
