English _119
● APPENDIX
Items
Description
SNF-8010 SNF-8010VM
Environmental
Operating Temperature /
Humidity
-10°C ~ +55°C (+14°F ~
+131°F) / Less than 90% RH
-30°C ~ +55°C (-22°F ~
+131°F) / Less than 90% RH
* Start up should be done at
above -25°C
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Ingress Protection - IP66
Vandal Resistance - IK10
Standard Certification
UL, CE, FCC, RoHS, Gost, KC
UL, CE, FCC, RoHS, Gost, KC,
EN-61373, EN-50155
Electrical
Input Voltage / Current
DC12V±10%, PoE
(IEEE802.3af, Class3)
DC12V±10%, PoE
(IEEE802.3af, Class3) mode
A only
Power Consumption Max 10.3W (PoE, Class3), Max 8.7W (DC 12V)
Mechanical
Color / Material IVORY, Aluminum
IVORY, Aluminum (Clear
Dome Cover)
Dimension (Ø x H) Ø145.9 x H49.6 mm Ø145.9 x H62.4 mm
Weight 780g 800g
