450Mbps Wireless N Router
Chapter 2. Connecting the Router
2.1 System Requirements
Broadband Internet Access Service (DSL/Cable/Ethernet)
One DSL/Cable Modem that has an RJ45 connector (which is not necessary if the Router is
connected directly to the Ethernet.)
PCs with a working Ethernet Adapter and an Ethernet cable with RJ45 connectors
TCP/IP protocol on each PC
Web browser, such as Microsoft Internet Explorer 5.0 , Netscape Navigator 6.0 or above
2.2 Installation Environment Requirements
Place the Router in a well ventilated place far from any heater or heating vent
Avoid direct irradiation of any strong light (such as sunlight)
Keep at least 2 inches (5 cm) of clear space around the Router
Operating Temperature: 0℃~40℃ (32℉~104℉)
Operating Humidity: 10%~90%RH, Non-condensing
2.3 Connecting the Router
Before installing the Router, make sure your PC is connected to the Internet through the
broadband service successfully. If there is any problem, please contact your ISP. After that, please
install the router according to the following steps. Don't forget to pull out the power plug and keep
your hands dry.
1. Power off your Cable/DSL Modem.
2. Locate an optimum location for the router. The best place is usually at the center of your
wireless network. The place must accord with the 2.2 Installation Environment Requirements
.
3. Adjust the direction of the antenna. Normally, upright is a good direction.
4. Connect the DSL/Cable modem to the Internet port on the router
.
5. Connect the PC to the Ethernet port on the router. (If you have the wireless NIC and want to
use the wireless function, you can skip this step.)
6. Connect the power adapter to the Power socket on the router, and the other end into an
electrical outlet. Then press the Power On/Off button to turn on the router.
7. Power on your Cable/DSL Modem.
