ZQ110
Rev. 1.00
- 60 -
Mobile Printer Command Manual
<Function 1> GS ( E pL pH fn d1 d2 (fn=1)
[Format]
[Range]
[Description]
[Notes]
ASCII
GS
(
E
pL
pH
fn
d1
d2
Hex
1D
28
45
pL
pH
fn
d1
d2
Decimal
29
40
69
pL
pH
fn
d1
d2
(pL + pH x 256) = 3 (pL=3, pH=0)
fn=1
d1=73, d2=78
This command starts the user setting mode, enabling the printer to notify
that the mode has changed as follows:
[Mode change feedback]
Hexadecimal
Decimal
Number of Data
Header
37H
55
1 byte
Flag
20H
32
1 byte
NUL
00H
0
1 byte
This command is effective only in standard mode, not in page mode.
Upon entering the user mode setting mode by this command, the printer
transmits “mode change feedback” to the host.
The user setting mode should be enabled prior to processing <Function
2> through 12. Otherwise, those functions are ignored.
After confirming “mode change feedback”, it is recommended to send the
command to reconfigure the NV user memory.
<Function 2> GS ( E pL pH fn d1 d2 d3 (fn=2)
[Format]
[Range]
[Description]
[Notes]
ASCII
GS
(
E
pL
pH
fn
d1
d2
d3
Hex
1D
28
45
pL
pH
fn
d1
d2
d3
Decimal
29
40
69
pL
pH
fn
d1
d2
d3
(pL + pH x 256) = 4 (pL=4, pH=0)
fn=2
d1=79, d2=85, d3=84
This command terminates the user setting mode and performs a software
reset.
This command activates setting items set in the user setting mode.
All the setting items will be effective only after performing this command.
After executing a software reset, the printer resumes the setting in effect
at power on.
