E-15
Tuner Q
Frequency range
FM: 87.5 - 108 MHz
AM: 530 - 1,710 kHz
Preset
40 (FM and AM station)
Speaker Q
Type
2-way type speaker system
2" (5 cm) tweeter
4-3/4" (12 cm) woofer
Maximum input power
160 W
Rated input power
80 W
Impedance
4 ohms
Dimensions
Width: 5 - 13/16" (148 mm)
Height: 8-11/16" (220 mm)
Depth: 7-9/16" (192 mm)
Weight
4.6 lbs (2.1 kg)/each
USB Q
USB host interface
Complies with USB 1.1 (Full O
Speed)/2.0 Mass Storage Class.
Support Bulk only and CBI protocol. O
Support fi le
MPEG 1 Layer 3 O
WMA (Non DRM) O
Bitrate support
MP3 (32 ~ 320 kbps) O
WMA (64 ~ 160 kbps) O
Other
Maximum total number of MP3/WMA O
fi les is 1024.
Maximum total number of folders is O
255 INCLUSIVE of root directory.
The ID3TAG information supported O
are TITLE, ARTIST and ALBUM
only.
Supports ID3TAG version 1 and O
version 2.
File system support
Support USB devices with Microsoft O
Windows/DOS/FAT 12/FAT 16/ FAT
32.
2 kbyte block length for sector. O
General Q
Specifi cations
As part of our policy of continuous improvement, SHARP reserves the right
to make design and specifi cation changes for product improvement without
prior notice. The performance specifi cation fi gures indicated are nominal
values of production units. There may be some deviations from these values
in individual units.
Power source
AC 120 V ~ 60 Hz
Power consumption
52 W
Dimensions
Width: 6 - 1/2" (165 mm)
Height: 8 - 2/3" (220 mm)
Depth: 9 - 1/4" (235 mm)
Weight
8.6 lbs. (3.9 kg)
CD player Q
Type
Single disc multi-play compact disc player
Signal readout
Non-contact, 3-beam
semiconductor laser pickup
D/A converter
Multi bit D/A converter
Frequency response
20 - 20,000 Hz
Dynamic range
90 dB (1 kHz)
Amplifi er Q
Output power
RMS: Total 160 watt (80 W per channel
into 4 ohms at 1 kHz, 10% Total
harmonic distortion.)
FTC: 60 watt minimum RMS per
channel into 4 ohms from 100 Hz
to 20 kHz, 10% Total harmonic
distortion.
Output terminals
Speakers: 4 ohms
20Hz - 20kHz
Video output: 1 Vp-p
Headphones: 16-50 ohms
(recommended: 32 ohms)
Input terminals
Audio In (audio signal):
250 mV/47 k ohms
Troubleshooting chart (continued)
Care of compact discs Q
Compact discs are fairly resistant to damage, however mistracking can occur
due to an accumulation of dirt on the disc surface. Follow the guidelines below
for maximum enjoyment from your CD collection and player.
Do not write on either side of the disc, particularly the non-label side from O
which signals are read. Do not mark this surface.
Keep your discs away from direct sunlight, heat, and excessive O
moisture.
Always hold the CDs by the edges. Fingerprints, dirt, or water on the O
CDs can cause noise or mistracking. If a CD is dirty or does not play
properly, clean it with a soft, dry cloth, wiping straight out from the center,
along the radius.
Cleaning the cabinet Q
Maintenance
Periodically wipe the cabinet with a soft cloth and a diluted soap solution,
then with a dry cloth.
Caution:
Do not use chemicals for cleaning (gasoline, paint thinner, etc.). It may O
damage the cabinet.
Do not apply oil to the inside of the unit. It may cause malfunctions. O
Cleaning the CD pickup lens Q
In order to ensure proper operation of the CD player, preventative maintenance
(cleaning of the laser pickup lens) should be performed periodically. Lens
cleaners are commercially available. Contact your local CD software dealer
for options.
