©2001 Nokia Mobile Phones. All rights reserved. 14
Table 2: GSM terminal light indicators
Power supply
The ACW-3 power supply is supplied with the terminal.
A backup battery set with its own power supply is also available, see “ Backup
battery set” on page 35.
Connect the power supply to the DC jack connector on the left side of the ter-
minal. After that, connect the power supply to the AC wall outlet.
345Description
---Power is off.
Blinking - - Power is on. The terminal is
attempting to connect to
the telephone network.
On - - In service.
On - On Call in progress.
On Blinking - The terminal has received a
call.
-
Blinking - Enter the PIN code.
Blinking Blinking - Enter the PUK code.
On On On The terminal has received an
SMS message or voice mail.
On On Blinking The terminal has no space
for new SMS messages. The
oldest message is
automatically deleted.
-
Blinking Blinking Install the SIM card.
Blinking Blinking Blinking An error has occured.
Contact service personnel.
