Setting up the terminal
©2001 Nokia Mobile Phones. All rights reserved. 18
3. Setting up the terminal
Before the Nokia 22 PBX connectivity terminal can be used it must be installed
properly.
In the following instructions it is assumed that the PIN code request and the
AutoPIN feature are active.
To use the Nokia 22 for the first time, proceed as follows:
1 Install the SIM card.
2 Mount the GSM terminal on the application module.
3 Connect the power supply to the terminal and to an AC wall outlet.
4 Connect a DTMF telephone to the terminal.
5 Enter the PIN code if your SIM card requires it.
6 Check the signal strength.
7 Install the external antenna.
8 Make test calls.
Warning! Do not connect the power supply to an AC wall outlet before
you have installed the SIM card and mounted the GSM terminal on the
application module.
Installing the SIM card
If the SIM card has not been installed, install it.
Insert the SIM card ensuring that the golden
contact area is facing downwards.
Note: Keep SIM cards always out of the reach of small children.The card
can be damaged by scratching or bending so it must be handled
carefully.
