Service Manual N73-1 RM-133 / N73-5 RM-133
Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 2.0
MGR
Page
(36)
7. Ensure the correct position of the new IHF GASKET 2.
8. Place the IHF SPEAKER 2 into the B-COVER and press it lightly to
stick it on correctly.
9. Position the GASKET IHF HOUSING onto its place paying
attention to the spring contacts of the IHF SPEAKER.
10. Place the FLASH LED into its socket and secure it carefully
with the SS-93.
11. Insert the ANTENNA MOULDING in the B-COVER...
12. ...and press it lightly into place.
