Menu Descriptions
61179641AL1-5C 5-147
Port Provisioning Menu
Port Provisioning
Main Menu\DSL Menus\DSL Provisioning\Port Provisioning\
NOTE
If expansion mode is enabled (refer to “Expansion Menu” on
page 5-90), the Select Shelf menu (see Figure 5-100) displays. A
host or client unit must be chosen in order to access the Port
Provisioning menu.
Figure 5-100. Select Shelf Menu
The Port Provisioning menu (see Figure 5-101) is used to select and set the ADSL ports.
TID: TA1248 Total Access 1248 MM/DD/YY HH:MM
Unacknowledged Alarms: None
Select Shelf
1. Host
2. Client 1 (configured)
3. Client 2 (configured)
4. Client 3 (configured)
Selection :
'?' - System Help Screen
