Feature Specification
Weight 230 g (65 W) and 285 g (90 W)
Dimensions 107*46*29.5 mm (65W) / 130*66 * 22 mm (90W)
Temperature range:
Operating 0 °C to 40 °C (32 °F to 104 °F)
Non-Operating –40 °C to 70 °C (–40 °F to 158 °F)
Table 29. Physical
Feature Latitude E7450 Non-
Touch
Latitude E7450 Touch
Front Height 18.8 mm (0.74 inch) 18.8 mm (0.74 inch)
Back Height 20.4 mm (0.8 inch) 22.6 mm (0.88 inch)
Width 337 mm (13.2 inches)
Depth 231.5 mm (9.1 inches)
Weight (with 3-cell
battery)
1.55 kg (3.42lb) 1.71 kg (3.77lb)
Light Weight Configurable Items:
Weight Bound 1.61 kg (3.56lb) 1.80 kg (3.97lb)
Weight Target 1.60 kg (3.54lb) 1.74 kg (3.84lb)
Table 30. Environmental
Feature Specification
Temperature:
Operating 0 °C to 60 °C (32 °F to 140 °F)
Storage –51 °C to 71 °C (–59 °F to 159 °F)
Relative humidity
(maximum):
Operating 10 % to 90 % (non condensing)
Storage 5 % to 95 % (non condensing)
Altitude (maximum):
Operating
–15.2 m to 3048 m (–50 to 10,000 ft)
0° to 35°C
Non-Operating –15.24 m to 10,668 m (–50 ft to 35,000 ft)
Airborne contaminant level G2 or lower as defined by ISA S71.04–1985
57
