Example
// Data Arrays
Data_Arrays
Data_Array_Name, Data_Format, Data_Array_Length,
DA_CIO, UInt16, 5143
DA_WR, UInt16, 511
DA_HR, Uint16, 511
DA_DM, Uint16, 32767
1.06 Driver Specific FieldServer Parameters
Section Title
FieldServer
Column Title Function Legal Values
Title Name for FieldServer Text
System_Node_Id
Specify physical node Id on
network.
This is the last byte of the
IP Address of the
FieldServer. eg. If
FieldServer’s IP Address is
192.168.1.81 then this
parameter should be set to
81
1-126
Example
// FieldServer Driver specific parameters
FieldServer
Title, System_Node_Id
Fins Client, 81
1.07 Client Side Connection Descriptors
Section Title
Adapter
Column Title Function Legal Values
Adapter Adapter Name N1, N2
2
Protocol Specify protocol used Fins, omn_fins or fins_udp
Udp_port_number Specify UDP port number 0, 9600 etc
2
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for
details of the ports available on specific hardware.
