4. Configuring the FieldServer as a FINS Client
For a detailed discussion on FieldServer configuration, please refer to the FieldServer
Configuration Manual. The information that follows describes how to expand upon the
factory defaults provided in the configuration files included with the FieldServer (See
“.csv” sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the
FieldServer to communicate with a FINS Server. As a Client this driver reads and writes
data to Server Nodes. Server nodes should be FINS capable and be configured to
communicate over FINS
1.05 Data Arrays/Descriptors
The configuration file tells the FieldServer about its interfaces, and the routing of
data required. In order to enable the FieldServer for FINS communications, the
driver independent FieldServer buffers need to be declared in the “Data Arrays”
section, the destination device addresses need to be declared in the “Client Side
Nodes” section, and the data required from the servers needs to be mapped in the
“Client Side Map Descriptors” section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value
being the default.
Section Title
Data_Arrays
Column Title Function Legal Values
Data_Array_Name Provide name for Data Array
Up to 15 alphanumeric
characters
Data_Array_Format
Provide data format. Each Data
Array can only take on one
format.
Float, Bit, UInt16,
SInt16, Packed_Bit,
Byte, Packed_Byte,
Swapped_Byte
Data_Array_Length
Number of Data Objects. Must
be larger than the data storage
area required by the Map
Descriptors for the data being
placed in this array.
1-32767
