Setting NMEA output mode:
1)
Press the MENU Key twice to select the Main Menu.
2)
Turn or move the FMS Joystick to select ‘System Setup’, and press the ENT
Key.
3)
Turn or move the FMS Joystick to select ‘Interface’, and press the ENT Key.
4)
With the ‘Serial Data Format’ field highlighted, turn the FMS Joystick to
select ‘NMEA In/Out’.
5)
Move the FMS Joystick to highlight the ‘NMEA Output Mode’ field.
6)
Turn the FMS Joystick to select ‘Normal’ or ‘Fast’.
NMEA Sentence Output:
Normal Mode: GPRMB, GPRMC, GPGGA, GPGSA, GPGSV, GPGLL, GPBWC, •
GPVTG, GPXTE, GPBOD, GPRTE, GPWPL, GPAPB, PGRME, PGRMZ, PGRMM,
and PGRMH.
Fast Mode: GPRMB, GPRMC, PGRMZ, and PGRMH.•
tis in t e r F A c e se t U p
Configuring TIS input:
1)
Press the MENU Key twice to select the Main Menu.
2)
Turn or move the FMS Joystick to select ‘System Setup’, and press the ENT
Key.
3)
Turn or move the FMS Joystick to select ‘Interface’, and press the ENT Key.
4)
With the ‘Serial Data Format’ field highlighted, turn the FMS Joystick to
select ‘TIS In’
or TIS In/NMEA & VHF Out
.
The TIS Status field indicates one of the following messages:
WaitingForData—searchingforavalidTISdatastream.•
DataAvailable—receivingTISdatafromthetransponder.•
DataUnavailable—connectiontotransponderestablished,butTISserviceis•
unavailable.
LostConnection—anerroroccurredortheconnectiontothetransponderwas•
lost.
