GPS Navigation
Overview GPS Navigation Flight Planning Hazard Avoidance Additional Features Appendices Index
5)
Turn the FMS Joystick to access the ‘On/Off’ drop down list.
6)
Turn or move the FMS Joystick to highlight the desired option, and press
the ENT Key.
MAP PANNING
Map panning allows the pilot to:
•Viewpartsofthemapoutsidethedisplayedrangewithoutadjustingthemap
range
•Highlightandselectlocationsonthemap
•Reviewinformationforaselectedairport,NAVAIDoruserwaypoint
•Designatelocationsforuseinightplanning
•Viewairspaceandairwayinformation
When the panning function is selected by pressing the FMS Joystick (PAN MAP
Softkey on the Weather Page) the Map Pointer flashes on the map display. A window
also appears at the top of the map display showing the latitude/longitude position
of the pointer, the bearing and distance to the pointer from the aircraft’s present
position, the elevation of the land at the position of the pointer, or the object’s (airports,
obstacles, etc) elevation, if known.
When the Map Pointer is placed on a map feature, the map feature is highlighted
and an information box appears (even if the name was not originally displayed on the
map).
Pressing the ENT Key displays a review page for the highlighted map feature. If
multiple features are present at the Map Pointer position, a green arrow will appear
in the information box. Turning the FMS Joystick will cycle through the list of map
features present at that position.
