Page 22SKU 96155 For technical questions, please call 1-800-444-3353.
PARTS LIST/DIAGRAM - REGULATING CONTROL SYSTEM
Part Description Q’ty Part Description Q’ty
1 Regulating Mount with Throttle 1 6 Regulating Arm Assy. 1
2 Choke Link 1 7 Nut (M6) 1
3 Pulling Rod 1 8 Regulating Arm Spring 1
4 Back Spring 1 9 Bolt (M6x12) 2
5 Lock Bolt 1
IMPORTANT
When ordering parts from the above Parts List, make sure to specify the following:
The PART NUMBER listed to the left of the part description.a.
The NAME OF THE PARTS LIST from which you are ordering (located at the top of this page).b.
