Illustrated parts catalog 21
Item Description Spare part number Customer self repair (on
page
)
cc) 3.33-GHz Intel Xeon processor X5680,
95W* **
594880-001 Optional
2
dd) 3.60-GHz Intel Xeon processor
X5687, 130W* **
638137-001 Optional
2
ee) 3.40-GHz Intel Xeon processor X5690,
130W* **
638136-001 Optional
2
13
Heatsink 508996-001 Optional
2
14
HP NC375i adapter 491838-001 Mandatory
1
15
I/O bezel 519562-001 Mandatory
1
16
Systems Insight Display 491837-001 Mandatory
1
Boards
17
System board 491835-001 Optional
2
18
Power supply backplane with cables 491836-001 Optional
2
19
8-bay SFF drive cage backplane
2
20
6-bay LFF backplane* 491840-001 Optional
2
21
2-bay LFF drive cage backplane* 511786-001 Optional
2
Storage devices
22
DVD-ROM drive 447464-001 Mandatory
1
23
Slimline optical drive* 481428-001 Mandatory
1
Miscellaneous
24
Rack mounting kit* 381679-001 Mandatory
1
Memory
25
DIMMs — —
a) PC3-8500R (DDR-1067) 4-GB RDIMM 501535-001 Mandatory
1
b) PC3-8500R (DDR-1067) 8-GB RDIMM 519201-001 Mandatory
1
c) PC3-10600R (DDR-1333) 2-GB RDIMM 501533-001 Mandatory
1
d) PC3-10600R (DDR-1333) 4-GB RDIMM 501534-001 Mandatory
1
e) PC3-10600R (DDR-1333) 16-GB
RDIMM
501538-001 Mandatory
1
f) PC3-1600R (DDR-1333) 16-GB RDIMM 632204-001 Mandatory
1
g) PC3-10600E (DDR-1333) 1-GB UDIMM 501539-001 Mandatory
1
h) PC3-10600E (DDR-1333) 2-GB UDIMM 501540-001 Mandatory
1
i) PC3-10600E (DDR-1333) 4-GB UDIMM 501541-001 Mandatory
1
Cables
26
Miscellaneous cable kit* 519565-001 Mandatory
1
a) SAS drive cable — —
c) I/O bezel cable assembly — —
d) Power on button cable — —
