164 Chapter 6
Configuration - Screens and Control Fields
Beeper Chan Space (User Defined)
Beeper
This field changes the audio beeper volume by selecting the desired
level from a list of choices (Off, Quiet, Loud). The beeper always beeps
when the instrument is turned on, regardless of this setting.
Operating Considerations
The beeper alerts you any time a message is displayed. Since a message
may be removed from the screen before you notice it, it is better to leave
the beeper on to alert you to errors during operation.
The beeper’s volume setting is retained when the instrument is turned
off.
Screen(s) Where Field is Present
INSTRUMENT CONFIGURE
Chan Space (User Defined)
This field specifies the RF channel spacing when the RF Display field
is set to Chan, and the RF Chan Std field is set to USER-DEF.
For example, entering 25 kHz causes a 25 kHz spacing between each
channel. If the receive frequency for channel 1 is 150.500 MHz, channel
2’s receive frequency would be 150.525 MHz.
Operating Considerations
The value of this field is only used if the RF Display field is set to
Chan, and the RF Chan Std field is set to USER-DEF.
For more information see the following related topics:
"Base Freq (User Defined)" field on page 163
"(Gen)-(Anl)" field on page 169
"RF Chan Std" field on page 175
Screen(s) Where Field is Present
INSTRUMENT CONFIGURE
