7
BASIC OPERATIONS
SwiTching power on/oFF
Press and hold for approximately 1 second to turn the transceiver power ON.
Press and hold again to turn the transceiver OFF.
■ Transceiver Password
If the transceiver is password protected, “PASSWORD” will appear on the
display when the power is turned ON. To unlock the transceiver, enter the
password:
1 Select a character using / .
• If you are using a microphone keypad, you can enter the password by direclty.
2 Press to enter the selected character.
• This step is unnecessary when using the keypad.
3 Repeat steps 1 and 2 to enter the entire password.
• Press or # to delete a character. Press and hold or # to delete all
characters.
4 Press or to confirm the entry.
• If you enter an incorrect password, an error tone sounds and the transceiver
remains locked.
• The password can contain a maximum of 6 digits.
AdjuSTing The volume
Press the keys programmed as Volume Up/ Volume Down to adjust the volume
level.
SelecTing A Zone And chAnnel
Select the desired zone using the keys programmed as Zone Up/ Zone Down.
Each zone contains a group of channels.
Select the desired channel using the keys programmed as Channel Up/
Channel Down. Each channel is programmed with settings for transmitting and
receiving.
• You can toggle the display between the zone and channel names and numbers by
pressing the key programmed as Display Format, or by accessing the Menu {page 9}.
TrAnSmiTTing
1 Select the desired zone and channel.
2 Press the key programmed as Monitor or Squelch Off to check whether or
not the channel is free.
• If the channel is busy, wait until it becomes free.
