Setup
PagePrinter Network Adapter: Utilities & Environments 2-3
TCP/IP
networks
Step 1: check the physical connections
First you need to make sure that your printer and adapter are installed and
working correctly. Check the following items.
• Make sure that the printer you want to use is installed on the LAN with the
appropriate Ethernet cable.
• Make sure that the adapter is installed in the printer. Instructions for setting up
the printer and installing adapters are shipped with the printer.
• Make sure that the printer is connected to the LAN with the appropriate
Ethernet cable.
Step 2: print a setup page
Next you need to print a setup page. Keep the setup page. You’ll use
information from it later.
Printing a setup page
1 Press the Test button on the adapter until the Test light comes on.
The Data light comes on, and the adapter sends a page to the printer,
similar to the one on page 2-4.
