Installing the Control Unit’s Housing
Installing the Front Cover
To install the front cover, see Figure 7-3 and follow these steps:
!Hook the top of the front cover onto the top cover.
!Push down on the bottom of the front cover until it locks securely
on the base of the wire manager on the modules.
Figure 7-3. Installing the Control Unit Front Cover
