SPECIFICATIONS

6-9

SPECIFICATIONS

Parallel Interface

The parallel connection is a bi-directional parallel interface and requires a standard

36-pin parallel cable and a parallel port available on the host computer. Do not

use a parallel cable longer than three meters (ten feet).

Table6-7 lists the parallel pin designations and associated signals.

Table 6-7. Parallel pin designations

Code Signal Pin

STROBE Strobe 1

D<0> Data 2

D<1> Data 3

D<2> Data 4

D<3> Data 5

D<4> Data 6

D<5> Data 7

D<6> Data 8

D<7> Data 9

ACK* Acknowledge 10

BUSY Busy 11

PE Paper Error 12

SEL Select Out 13

AUTOFD* Auto Feed 14

(N/C) (Not Connected) 15

GND Ground 16

GND Ground 17

+5 VDC 5 Volts Direct Current 18

GND Ground 19

GND Ground 20

GND Ground 21

GND Ground 22

GND Ground 23

GND Ground 24

GND Ground 25

GND Ground 26

GND Ground 27

GND Ground 28

GND Ground 29

GND Ground 30

INIT* Initialization 31

FAULT* Fault 32

(N/C) (Not Connected) 33

(N/C) (Not Connected) 34

(N/C) (Not Connected) 35

SELIN Select In 36
