Specifications
Gas Units
Delivery (GPM) 1.2
(LPM) 4.5
Cycles per gallon 87
Cycles per liter 23
Cycles per minute (maximum) 104
Maximum Tip Size - 1 Gun .034"
Maximum Tip Size - 2 Guns .025"
Maximum Tip Size - 3 Guns .019"
Pressure Range (psi) 400 - 3300
Pressure Range (bar) 28 - 228
Power Honda 4.0 HP, 4-Stroke,
Single Cylinder, Overhead Valve Engine With Oil Alert
Fuel Capacity 0.66 US Gallons
(Approximately 3 hours run time)
Halogenated Solvent Compatible Yes
Weight 139 Lbs. (63 Kg.)
Inlet Paint Filter 10 Mesh "Rock Catcher"
Outlet Paint Filter 50 Mesh, 18 in.
2
Pump Inlet 3/4" NPT(F)
Pump Outlet 1/2" NPT(F) to Paint Filter
Paint Filter Hose Connections (1) - 1/4" NPS(M)
(1) - 3/8" NPT(F) Plugged
Dimensions 30" H (787 mm) x 34" L (864 mm) x 23" W (584 mm)
Fluid Pump Wetted Parts Electroless nickel plated ductile iron, electroless nickel plated carbon steel, propri-
etary Severe Service 500™ hard chrome anti-wear surface, stainless steel, tungsten
carbide, 37)(, thiokol impregnated leather, ultra high molecular weight polyethylene.
Electric Units
DC - Electric
Delivery (GPM) 1.10
(LPM) 4.20
Cycles per gallon 87
Cycles per liter 23
Cycles per minute (maximum) 96
Maximum Tip Size - 1 Gun .031"
Maximum Tip Size - 2 Guns .023"
Maximum Tip Size - 3 Guns .017"
Pressure Range (psi) 400 - 3300
Pressure Range (bar) 28 - 228
Power 2 HP DC Motor
115V, 16 AMP
230V, 8 AMP
Overload Protected
Halogenated Solvent Compatible Yes
Weight 158 Lbs. (72 Kg.)
Inlet Paint Filter 10 Mesh "Rock Catcher"
Outlet Paint Filter 50 Mesh, 18 in.
2
Pump Inlet 3/4" NPT(F)
Pump Outlet 1/2" NPT(F) to Paint Filter
Paint Filter Hose Connections (1) - 1/4" NPS(M)
(1) - 3/8" NPT(F) Plugged
Dimensions 30" H (787 mm) x 34" L (864 mm) x 23" W (584 mm)
Fluid Pump Wetted Parts Electroless nickel plated ductile iron, electroless nickel plated carbon steel, propri-
etary Severe Service 500™ hard chrome anti-wear surface, stainless steel, tungsten
carbide, 37)( thiokol impregnated leather, ultra high molecular weight polyethylene.
