Control Rules
Object:
Specify the object for the entry. You can select “Group” to limit the
predefined group, or select “ANY” to limit all the users.
Group:
If select “Group” as object, you can select the group in the drop-down list.
To establish new group, please refer to 3.2.1 Group.
Application:
Click the <Application List> button to select applications from the popup
checkbox. The applications include IM, Web IM, SNS, P2P, Media, Basic
and Proxy. The default setting is to limit all the applications in the
application list except for Basic and Proxy.
Effective Time:
Specify the time for the entry to take effect.
Description:
Give a description for the entry.
Status:
Activate or inactivate the entry.
List of Rules
You can view the information of the entries and edit them by the Action buttons.
The first entry in Figure 3-55 indicates: The group1 is applied with Application Rules. You can click
<View> to view the limited applications in the popup checkbox. The effective time of this entry is
7:00-9:00 on Monday, Tuesday, Friday, Saturday and Sunday. This entry is enabled.
Note:
To set the group and group members, please refer to 3.2.1 Group.
3.4.5.2 Database
On this page, you can upgrade the application database.
Choose the menu Firewall→App Control→Database to load the following page.
Figure 3-56 Database
-78-
