6 SPARC Enterprise M4000/M5000 Servers Product Notes for XCP Version 1050 September 2007
Cautions for mounting the server in the 19-inch
rack
When you mount the SPARC Enterprise M4000 or M5000 server on the 19-inch rack,
as you insert it all the way seated in the rack, the nut anchoring the bezel may
interfere with the rack column and the server may fail to be seated correctly.
In such a case, please replace the bezel anchoring nut and ring with the E-Ring.
1. Remove the interfering bezel anchoring nut and ring.
M4000 (4 places)
M5000 (6 places)
Ring Bezel Anchoring nut
