NOTE:

1. To reduce the chance of losing data, ALi imposed limitations on the

RAID configuration options. For example, Parallel-ATA drives

connected on the same IDE channel cannot be selected as the

members of a RAID1 array. Mixing Parallel- and Serial-ATA disk drives

in a RAID1 array should also be avoided.

2. Always use disk drives of the same capacity to create a RAID array.

The excessive capacity of a larger disk drive cannot be utilized because

data mirrors are equally distributed across corresponding members of

drive pairs within a RAID array. The operational concept is

diagrammed below.

2.3 Create JBOD for Integrated Capacity

Step 1. JBOD stands for “Just a Bunch of Drives.” JBOD provides neither

performance gains nor data redundancy. To create a JBOD array, use

your arrow keys to highlight and press Enter to activate this item. A ‘J’

C-11
