13. EXPLODED VIEW & REPLACEMENT PART LIST
LGE Internal Use Only
Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Level
Location
No.
Description Part Number Spec Color
Remark
6 C514 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6 C515 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6 C516 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6 C517 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6 C518 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6 C519 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6C520 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6C521 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6C522 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6C523 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6C524 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6C525 CAP,CERAMIC,CHIP ECCH0010501
7.5 pF,50V ,D ,X7R ,TC ,1005 ,R/TP ,; ,C0G TYPE(No
X7R) ,[empty] ,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
6C526 CAP,CERAMIC,CHIP ECCH0000117 27 pF,50V,J,NP0,TC,1005,R/TP
6C527 CAP,CERAMIC,CHIP ECCH0000117 27 pF,50V,J,NP0,TC,1005,R/TP
6C528 CAP,CERAMIC,CHIP ECCH0000117 27 pF,50V,J,NP0,TC,1005,R/TP
6C529 CAP,CERAMIC,CHIP ECCH0000117 27 pF,50V,J,NP0,TC,1005,R/TP
6C530 CAP,CERAMIC,CHIP ECCH0000117 27 pF,50V,J,NP0,TC,1005,R/TP
6C531 CAP,CERAMIC,CHIP ECCH0000117 27 pF,50V,J,NP0,TC,1005,R/TP
6C532 CAP,CERAMIC,CHIP ECCH0000117 27 pF,50V,J,NP0,TC,1005,R/TP
6C533 CAP,CERAMIC,CHIP ECCH0000117 27 pF,50V,J,NP0,TC,1005,R/TP
6C534 CAP,CERAMIC,CHIP ECCH0004904
1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP
