Getting to Know Your Phone
Some menus/features are operator dependent.
7
Getting to Know Your Phone
Diagrams
The following diagrams illustrate the front, back (with
back cover removed), and bottom views of your phone.
Standby Screen Icons
Once the phone powers up, you will see the standby
screen. You will also see the standby screen when you exit
the menu system. These are all of the icons that could
appear on your standby screen.
1 Antenna
2 Earpiece
3 Side Volume Keys
4 Display
5 Left Softkey
6 Keypad
7 Headset Jack
8 Joystick
(4-way navigation
with center select key)
9 Right Softkey
10 Power (On/Off) Key
2
3
5
6
7
8
9
10
4
1
11 External Antenna Connector
12 Guide for Attaching Back
Cover
13 Back Cover Latch
14 Battery Connector
15 Accessory Connector
(Handsfree, Charger, FM
Radio, MP3, Chatboard, etc.)
