FPL GROUP: CHARTS PAGE
Charts Page (Optional)
Soft Keys Found on Charts Page
Change Day/Night View
While viewing the Charts page of the FPL Page Group, press the 1) MENU key
to display the Options menu.
Press 2) ENT to go to Chart Setup. The Color Scheme option will be highlighted.
Turn the small 3) MFD knob to select Day - Auto - Night.
Press the small 4) MFD knob to save the selected value and return to the Charts
page.
If “Auto” is selected, turn the large 5) MFD knob to highlight the Display Level
Brightness value. Turn the small MFD knob to change the display level value
for which the display will automatically switch from Day/Night brightness.
Press the 6) ENT key to save the selected value.
Viewing Charts and Panning
While viewing the Charts page of the FPL Page Group, press the 1) RNG (Range)
keys to zoom in and out.
Press the small 2) MFD knob to enter the panning mode and activate scroll bars
on the edges of the chart.
Turn the large 3) MFD knob to move around the chart horizontally and turn the
small MFD knob to move vertically.
Press the small 4) MFD knob to cancel the scroll bars and exit panning.
NOTE: Panning mode is available when scroll bars are present.
