134 Chapter 8 Printer parts EN
Developing carousel assembly
Ref Description Qty
Parts for 4500
s/n xxG and
below
Parts for 4500
s/n xxH and
above
Parts for 4550
1 Fan, large 1 RH7-1346-
000CN
RH7-1435-
000CN
RH7-1435-
000CN
2 Spacer 1 RS5-6210-
000CN
RS5-6210-
000CN
RS5-6210-
000CN
3 Bearing,
carousel
1 XG9-0361-
000CN
XG9-0361-
000CN
XG9-0361-
000CN
4 Gear, 125T 1 RS6-0176-
000CN
RS6-0176-
000CN
RS6-0176-
000CN
5 Developing
PCB
1 RG5-3811-
000CN
RG5-5180-
000CN
RG5-5180-
000CN
6 Carousel drive
assembly
1 RG5-5209-
000CN
RG5-5209-
000CN
RG5-5209-
000CN
7 Cable, fusing
connector
1 RG5-3886-
000CN
RG5-3886-
000CN
RG5-3886-
000CN
8 Cable, rotary 1 RG5-3795-
000CN
RG5-3795-
000CN
RG5-3795-
000CN
9
Sensor (PS12),
toner level
1 RG5-3355-
000CN
RG5-3355-
000CN
RG5-3355-
000CN
10 Sensor,
(PS10)
carousel
position
1 WG8-5362-
000CN
WG8-5362-
000CN
WG8-5362-
000CN
11 Carousel
assembly
1 RG5-5249-
000CN
RG5-5249-
000CN
RG5-5249-
000CN
12 Spring, toner
flap
2 RS5-2739-
000CN
RS5-2739-
000CN
RS5-2739-
000CN
