Illustrated parts catalog 18
Item Description
Spare part
number
Customer
self repair
(on page 5)
b) QLogic QMH2462 4Gb FC HBA for HP c-Class
BladeSystem
405920-001 Mandatory
1
c) HP NC325m PCI Express Quad Port Gigabit Server
Adapter for c-Class BladeSystem
436011-001 Mandatory
1
d) HP NC326m PCI Express Dual Port 1Gb Server Adapter for
c-Class BladeSystem
419330-001 Mandatory
1
e) HP NC360m HBA for c-Class BladeSystem 448068-001 Mandatory
1
f) HP NC364m Quad Port 1GbE BL-c Adapter 448066-001 Mandatory
1
g) HP NC373m PCI Express Dual Port Multifunction Gigabit
Server Adapter for c-Class BladeSystem
430548-001 Mandatory
1
h) HP PCIe Mezzanine Pass-thru card 436010-011 Mandatory
1
i) HP NC512m Dual Port 10GbE Multifunction BL-c Adapter 448515-001 Mandatory
1
15 Handle kit* 434104-001 Mandatory
1
a) Server blade handle — —
b) Release button — —
c) Server blade handle screw, Phillips head — —
d) Release button screws, T-15 (2) — —
e) Server blade handle nut — —
16 Hardware and plastics kit* 436381-001 Mandatory
1
a) Processor blank — —
b) Device bay blank coupler — —
c) Connector cover, enclosure connector 1 — —
d) Connector cover, enclosure connector 2 — —
e) Rear access panel support — —
f) DIMM baffle, front — —
g) DIMM baffle, rear — —
* Not shown
**Do not mix processors with different model numbers, speeds, cache sizes, or power consumption.
1
Mandatory—Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be
charged for the travel and labor costs of this service.
2
Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If,
however, you require that HP replace them for you, there may or may not be additional charges, depending on the
type of warranty service designated for your product.
3
No—Some HP parts are not designed for customer self repair. In order to satisfy the customer warranty, HP requires
that an authorized service provider replace the part. These parts are identified as "No" in the Illustrated Parts
Catalog.
1
Mandatory: Obligatoire—Pièces pour lesquelles la réparation par le client est obligatoire. Si vous demandez à HP
de remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés.
