Navigation by Dragging Inside IPIX Images
IPIX images may be navigated by dragging inside images. If your mouse pointer changes to
when placed over the images from an IPIX camera, navigation by dragging is supported for the
camera. Refer to the release note for information about supported features for individual IPIX
cameras.
PTZ Navigation Buttons
As an alternative to navigation by dragging inside IPIX images, use the navigation buttons in the
PTZ Control section to move around the view from the selected IPIX camera.
The round middle button lets you quickly move the camera to its home (i.e. default) position. The
plus and minus buttons lets you zoom in and out respectively.
Tip: If you mouse has a scroll wheel, you can also use the scroll wheel to control the zoom
level. On many mice, clicking the scroll wheel or middle mouse button quickly lets you view the
whole image again.
PTZ Control section
Presets
The Presets list does not apply for navigating already recorded images.
IPIX PTZ Positions
You are able to move to a specific position in the IPIX view, and then save that position by clicking
the Save button. When you later want to return to the saved position, click the Load button.
Digital Zoom
By selecting the PTZ Control’s Digital Zoom check box, you are able to use digital zoom on images
from any camera displayed in the view. When digital zoom is enabled, you will see a small
overview frame in the bottom right corner of each of the view’s camera positions. Once you zoom
in on an area of an image, the overview frame will help you maintain an overview of the complete
image:
Overview frame inside image
