Page 111FT-2000 OPERATING MANUAL
GROUP NO. MENU FUNCTION AVAILABLE VALUES DEFAULT SETTING
SCOPE 107 SCP 5.0 FI 5.250 - 5.499 MHz (1 kHz/step) 5.250 MHz
1
SCOPE 108 SCP 7.0 FI 7.000 - 7.299 MHz (1 kHz/step) 7.000 MHz
1
SCOPE 109 SCP 10.1 FI (1)0.100 - (1)0.149 MHz (1 kHz/step) (1)0.100 MHz
1
SCOPE 110 SCP 14.0 FI (1)4.000 - (1)4.349 MHz (1 kHz/step) (1)4.000 MHz
1
SCOPE 111 SCP 18.0 FI (1)8.000 - (1)8.199 MHz (1 kHz/step) (1)8.068 MHz
1
SCOPE 112 SCP 21.0 FI (2)1.000 - (2)1.449 MHz (1 kHz/step) (2)1.000 MHz
1
SCOPE 113 SCP 24.8 FI (2)4.800 - (2)4.989 MHz (1 kHz/step) (2)4.890 MHz
1
SCOPE 114 SCP 28.0 FI (2)8.000 - (2)9.699 MHz (1 kHz/step) (2)8.000 MHz
1
SCOPE 115 SCP 50.0 FI (5)0.000 - (5)3.999 MHz (1 kHz/step) (5)0.000 MHz
1
TUNING 116 tun DIALSTEP 1 or 10 Hz 10 Hz
TUNING 117 tun CW FINE EnA/diS diS
TUNING 118 tun MHz SEL 1/0.1 MHz 1 MHz
TUNING 119 tun AM STEP 2.5/5/9/10/12.5 kHz 5 kHz
TUNING 120 tun FM STEP 5/6.25/10/12.5/25 kHz 5 kHz
TUNING 121 tun FM DIAL 10/100 Hz 100 Hz
TUNING 122 tun MY BAND 1.8 ~ 50/GE/AU ––
TX AUDIO 123 tAUd EQ1 FRQ OFF/100 ~ 700 Hz (100 Hz/step) OFF
TX AUDIO 124 tAUd EQ1 LVL –10 ~ +10 +5
TX AUDIO 125 tAUd EQ1 BW 1 ~ 10 10
TX AUDIO 126 tAUd EQ2 FRQ OFF/700 ~ 1500 Hz (100 Hz/step) OFF
TX AUDIO 127 tAUd EQ2 LVL –10 ~ +10 +5
TX AUDIO 128 tAUd EQ2 BW 1 ~ 10 10
TX AUDIO 129 tUAd EQ3 FRQ OFF/1500 ~ 3200 Hz (100 Hz/step) OFF
TX AUDIO 130 tUAd EQ3 LVL –10 ~ +10 +5
TX AUDIO 131 tUAd EQ3 BW 1 ~ 10 10
TX AUDIO 132 tAUd PE1 FRQ OFF/100 ~ 700 Hz (100 Hz/step) 200 Hz
TX AUDIO 133 tAUd PE1 LVL –10 ~ +10 –10
TX AUDIO 134 tAUd PE1 BW 1 ~ 10 2
TX AUDIO 135 tAUd PE2 FRQ OFF/700 ~ 1500 Hz (100 Hz/step) 800 Hz
TX AUDIO 136 tAUd PE2 LVL –10 ~ +10 –3
TX AUDIO 137 tAUd PE2 BW 1 ~ 10 1
TX AUDIO 138 tUAd PE3 FRQ OFF/1500 ~ 3200 Hz (100 Hz/step) 2100 Hz
TX AUDIO 139 tUAd PE3 LVL –10 ~ +10 +6
TX AUDIO 140 tUAd PE3 BW 1 ~ 10 1
TX GNRL 141 tGEn BIAS –– ––
2
TX GNRL 142 tGEn MAX PWR 10/20/50/100 W 100 W
TX GNRL 143 tGEn PWRCTRL ALL/Car ALL
TX GNRL 144 tGEn ETX-GND EnA(ENABLE)/diS(DISABLE) diS(DISABLE)
TX GNRL 145 tGEn TUN PWR 10/20/50/100 W 100 W
TX GNRL 146 tGEn VOX SEL nic/dAtA nic
TX GNRL 147 tGEn EMRGNCY EnA(ENABLE)/diS(DISABLE) diS(DISABLE)
1: Requires optional DMU-2000 Data Management Unit.
2: This Menu item does not work. Please do not change this setting.
MENU MODE
