Page 121FT-2000 OPERATING MANUAL
RX DSP GROUP
092 rdSP NOTCH W
Function: Selects the bandwidth of the DSP NOTCH fil-
ter
Available Values: nArr (Narrow)/uuid (Wide)
Default Setting: uuid (Wide)
093 rdSP CW SHAP
Function: Selects the passband characteristics of the DSP
filter for the CW mode.
Available Values: SOFt/ShAP
Default Setting: ShAP
SOFt (SOFT): Primary importance is attached to the
amplitude of the filter factor.
ShAP (SHARP):Primary importance is attached to the
phase of the filter factor.
094 rdSP CW SLP
Function: Selects the shape factor of the DSP filter for
the CW mode.
Available Values: StP(STEEP)/nEd(MEDIUM)/
GEnt(GENTLE)
Default Setting: nEd (MEDIUM)
095 rdSP CW NARR
Function: Selects the passband of the DSP filter for the
CW “Narrow” mode.
Available Values: 25/50/100/200/300/400/500/800/1200/
1400/1700/2000 Hz
Default Setting: 500 Hz
MENU MODE
096 rdSP PKT SHP
Function: Selects the passband characteristics of the DSP
filter for the PKT mode.
Available Values: SOFt/ShAP
Default Setting: ShAP
SOFt (SOFT): Primary importance is attached to the
amplitude of the filter factor.
ShAP (SHARP):Primary importance is attached to the
phase of the filter factor.
097 rdSP PKT SLP
Function: Selects the shape factor of the DSP filter for
the PKT mode.
Available Values: StP(STEEP)/nEd(MEDIUM)/
GEnt(GENTLE)
Default Setting: nEd (MEDIUM)
098 rdSP PKT NAR
Function: Selects the passband of the DSP filter for the
PKT “Narrow” mode.
Available Values: 25/50/100/200/300/400 Hz
Default Setting: 300 Hz
099 rdSP RTY SHP
Function: Selects the passband characteristics of the DSP
filter for the RTTY mode.
Available Values: SOFt/ShAP
Default Setting: ShAP
SOFt (SOFT): Primary importance is attached to the
amplitude of the filter factor.
ShAP (SHARP):Primary importance is attached to the
phase of the filter factor.
100 rdSP RTY SLP
Function: Selects the shape factor of the DSP filter for
the RTTY mode.
Available Values: StP(STEEP)/nEd(MEDIUM)/
GEnt(GENTLE)
Default Setting: nEd (MEDIUM)
101 rdSP RTY NAR
Function: Selects the passband of the DSP filter for the
RTTY “Narrow” mode.
Available Values: 25/50/100/200/300/400 Hz
Default Setting: 300 Hz
IF
BANDWIDTH
“+” Gain
“Q”
“
--
” Gain
CONTOUR “GAIN” AND “Q”
090 rdSP CNTR LV
Function: Adjusts the parametric equalizer gain of the
Contour filter.
Available Values: –40 ~ +20 dB
Default Setting: –15 dB
091 rdSP CNTR WI
Function: Adjusts the Q-factor of the Contour filter.
Available Values: 1 - 11
Default Setting: 10
