Phone Overview
14
1. Camera Lens Use to take photos. Keep it clean for
optimal photo quality.
2. Front LCD Screen Displays the digital clock and
phone status.
3. Earpiece Lets you hear the caller and automated
prompts.
4. Flip Use to make or answer calls. Flip open to reveal
the keypad to dial a number or answer an incoming
call. Close the flip to end the call.
5. Main LCD Screen Displays messages, indicator
icons and active functions.
6. OK Key / Directional Key Use the OK Key to
select the function displayed at the bottom of the
LCD between the Left and Right Soft Key functions.
Use the Directional Key to scroll through the
menu items and highlight a specific field or object
by moving up, down, left or right.
7. Left Soft Key Performs functions identified on the
bottom-left corner of the screen.
8. Speakerphone Key Use to change to
speakerphone mode.
9. Headset JackAllows you to plug in an optional
2.5mm headset for convenient, hands-free
conversations.
10. SEND Key Use to make and answer calls. Press to
access the All Calls list.
11. Volume Keys Use to adjust the Master Volume in
standby mode* and the Earpiece Volume during a
call. Use to adjust font sizes when viewing
messages, entering phone numbers (in standby
mode) or browsing menus (except for the Main
menu).
12. Charger/Accessory Port Connects the phone to
the Wall/USB charger, or other compatible
accessories.
* Standby mode is when the phone is waiting for input from you. No
menu is displayed and the phone isn’t performing any action. It’s the
starting point for all of the instruction steps.
4. Flip
11. Volume Keys
14. Right Soft Key
5. Main LCD Screen
6. OK Key /
Directional Key
8. Speakerphone Key
7. Left Soft Key
12. Accessory/Charger
Port
3. Earpiece
10. SEND Key
19. Vibrate Mode
Key
15. CLR/ Voice Commands
Key
17. PWR/END Key
18. Alphanumeric
Keypad
16. Camera Key
9. Headset Jack
13. International Call Prefix Key
20. Microphone
1. Camera Lens
2. Front LCD
Screen
