Inserting your battery
Put the contacts of the battery into the
hole located at the bottom of the unit,
as shown in the following picture.
Press the upper side of the battery until
you hear the “click”.
Removing your battery
Push the battery-lock key up and
remove the battery.
Charging your battery
Your phone uses a Li-Ion battery. Make sure
to use an authorized battery and charger
only. For more details, please inquire at your
nearest dealer.
You can use your phone when the battery is
being recharged.
When the battery is inserted in your phone,
open the protective cover located on the
bottom of your phone and connect the
charger adapter, as shown below. A suitable
adapter is supplied with your phone.
When your battery is fully charged,
remove the adapter connection from the
outlet, then disconnect the adapter from
your phone by pressing the adapter’s
side buttons and pulling the adapter
away from your phone, as shown below.
•Do not use a damaged battery or charger.
•Use your battery for the specified purpose only.
• The closer you are to your network’s base station, the
longer your phone usage time because less battery
power is consumed for the connection.
• The battery recharging time varies depending on the
remaining battery capacity and the battery and charger
type you use.
Battery
16
Tip
Your phone is powered by a Lithium Ion (Li-Ion) battery.
This means that, unlike other forms of battery technology, you can
recharge your battery while some charge remains without reducing
your phone’s autonomy due to the “battery memory effect” inherent
in those technologies.
