4.4.26. Map Descriptor Example 23 - read start time
// Client Side Map Descriptors
Map Descriptor
Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length
Start_Time, 0s, Start_Time, 0, rdbc, SYSPLUS_01, Start_Time, 4
The retrieved start time will be stored as follows in Data_Array_Name:
Offset from Data_Array_Offset Description
0 Month
1 Day
2 Hour
3 Minute
4.4.27. Map Descriptor Example 24 - read stop time
// Client Side Map Descriptor
Map Descriptor
Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length
Stop_Time, 0s, Stop_Time, 0, rdbc, SYSPLUS_01, Stop_Time, 4
The retrieved stop time will be stored as follows in Data_Array_Name:
Offset from Data_Array_Offset Description
0
Month
1 Day
2 Hour
3 Minute
4.4.28. Map Descriptor Example 25 - read audible alarm
// Client Side Map Descriptors
Map Descriptor
Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Length
Audible_Alarm, 0s, Audible_Alarm, 0, rdbc, SYSPLUS_01, Audible_Alarm, 1
The status of the audible alarm will be stored as 1 for “on” or 0 for “off” in Data_Array_Name at Data_Array_Offset.
