4.4.80. Map Descriptor Example 77 - set stop time = month/day hour:minute
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function,
Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length
Set_Stop_Time, Par_Bit_Triggers, 2, awt, SYSPLUS_01, Set_Stop_Time, Set_Stop_Time, 0, 1
This command is used by first writing the parameter data and then triggering the command by writing any value to Data_Array_Name
at Data_Array_Offset.
Parameter data setup:
Offset from par_data_array_offset Description
0
Month
1
Day
2
Hour
3
Minute
4.4.81. Map Descriptor Example 78 - set date = month / day / year
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function,
Node_Name, SysPlus_Cmd, Par_Data_Array_Name, Par_Data_Array_Offset, Length
Set_Date, Par_Bit_Triggers, 3, awt, SYSPLUS_01, Set_Date, Set_Date, 0, 1
This command is used by first writing the parameter data and then triggering the command by writing any value to Data_Array_Name
at Data_Array_Offset.
Parameter data setup:
Offset from par_data_array_offset Description
0
Month
1
Day
2
Year
