4.4.116. Map Descriptor Example 112 - edit read gsoak enabled channel
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function,
Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Gsoak_Ena, Rd_Par_Triggers, 1, art, SYSPLUS_01, Ed_Rd_Gsoak_Ena, Ed_Rd_Gsoak_Ena, 0, 1
This command is triggered by writing channel to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows: ( A value of 1 is used for “true” or 0 for “false” )
Offset from Store_Data_Array_Offset
Description
0 Gsoak enabled
4.4.117. Map Descriptor Example 113 - edit read gsoak channel
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Gsoak, Rd_Par_Triggers, 2, art, SYSPLUS_01, Ed_Rd_Gsoak, Ed_Rd_Gsoak, 0, 1
This command is triggered by writing channel to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset
Description
0 Gsoak value
4.4.118. Map Descriptor Example 114 - edit read scan alarm
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, SysPlus_Alarm_Name, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Scan_00, Scan_Alm_Trigs, 0, art, SYSPLUS_01, Ed_Rd_Scan, fire, Ed_Rd_Scan, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows: ( A value of 1 is stored for “Fail” or 0 for “Normal” )
Offset from Store_Data_Array_Offset
Description
0 Alarm status
