4.4.104. Map Descriptor Example 100 - edit read fuzzy cool cycle time
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Fuz_Cct, Rd_Triggers, 16, art, SYSPLUS_01, Ed_Rd_Fuz_Cct, Ed_Rd_Fuz_Cct, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset
Description
0 Cool cycle time
4.4.105. Map Descriptor Example 101 - edit read fuzzy heat sensitivity
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function,
Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Fuz_HSens, Rd_Triggers, 17, art, SYSPLUS_01, Ed_Rd_Fuz_HSens, Ed_Rd_Fuz_HSens, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset
Description
0 Heat sensitivity
4.4.106. Map Descriptor Example 102 - edit read fuzzy cool sensitivity
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function,
Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Fuz_CSens, Rd_Triggers, 18, art, SYSPLUS_01, Ed_Rd_Fuz_CSens, Ed_Rd_Fuz_CSens, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset
Description
0 Cool sensitivity
