4.4.91. Map Descriptor Example 87 - edit read duration
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Duration, Rd_Triggers, 3, art, SYSPLUS_01, Ed_Rd_Duration, Ed_Rd_Duration, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset
Description
0
Duration
4.4.92. Map Descriptor Example 88 - edit read events
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Events, Rd_Triggers, 4, art, SYSPLUS_01, Ed_Rd_Events, Ed_Rd_Events, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset
Description
0
Event0 status
..
..
9
Event9 status
