Using Combinations
USinG
CombinationS
Using Combinations
The Combinations screen displays a combination of different screens at the same time. The number
of options available on the Combinations screen depends on the optional network devices you
have connected to your GPSMAP 4000 series chartplotter, and whether you are using an optional
BlueChart g2 Vision SD card. You can combine two or three screens.
Selecting a Combination
1. From the Home screen, select Combinations. The Combinations screen shows a list of possible
screen combinations.
2. Select a combination.
Interacting with the Combinations Screen
The Combinations screen shows a list of possible screen combinations. When viewing three
combination screens, one screen is larger than the others. The charts are numbered with a
corresponding button in the lower-right corner.
Switch focus screen
Focus screen
Data elds
To switch the focus screen:
Select the icon in the lower-right corner that represents the screen you want.
To change the function of a screen:
1. Select Menu > Change Combination. The charts are numbered, with a corresponding button on
the right of the screen.
2. Select the numbered button of the screen you want to change.
3. Select the function that you want to appear on the selected screen.
To view the focus screen at full screen:
1. Use the Rocker to move the pointer.
2. Select an option to return to the Combinations screen:
From the Radar screen select Stop Pointing.
From the Chart screen, select Stop Panning.
From the Sonar or Video screen, select Back.
•
•
•
