GPSMAP 4000 Series Owner’s Manual 31
Viewing Information
VieWinG
information
5. From the Send to Device window, select the drive for the SD card reader and the types of data
you want to copy to your chartplotter.
6. Click Send.
7. Insert the SD card into your chartplotter.
8. From the Home screen on your chartplotter, select Information > User Data > Data Transfer >
Card.
9. Complete one of the following:
Select Merge From Card to transfer data from the SD card to the chartplotter and combine it
with existing user data.
Select Replace From Card transfer data from the SD card to the chartplotter and overwrite
existing user data on the chartplotter.
10. Select the le name from the list.
11. Select Merge from Card or Replace from Card.
To transfer waypoints, routes, tracks to an SD card:transfer waypoints, routes, tracks to an SD card:
1. Insert an SD card into the SD card slot on the front of the chartplotter.
2. From the Home screen, select Information > User Data > Data Transfer > Card > Save To
Card.
3. Complete one of the following actions to indicate the name of the new le:
Select a le name from the list.
Select Add New File to create a new le. Enter the le name using the Rocker or Numeric
Keypad (GPSMAP 4210 or 4212 only) and select Done.
4. Select Save To Card to save waypoints, routes, and tracks to the SD card. The le name is
saved with an .ADM extension.
To transfer waypoints, routes, and tracks from an SD card:transfer waypoints, routes, and tracks from an SD card:
1. Insert an SD card into the SD card slot on the front of the chartplotter.
2. From the Home screen, select Information > User Data > Data Transfer > Card.
3. Select an option to indicate how existing data on the chartplotter is handled:
Select Merge From Card to transfer data from the SD card to the chartplotter and combine it
with existing user data.
Select Replace From Card to transfer data from the SD card to the chartplotter and overwrite
existing user data on the chartplotter.
4. Select the le name from the list.
5. Select Merge from Card or Replace from Card.
To copy the built-in maps to an SD card:
1. Insert an SD card into the SD card slot on the front of the chartplotter.
2. From the Home screen, select Information > User Data > Data Transfer > Card.
3. Select Copy Built-In Map to copy the maps loaded onto your chartplotter to the SD card.
•
•
•
•
•
•
