After setting up a basic internet access point for packet
data (GPRS), select Options > Advanced settings,
and define the following advanced settings:
• Network type — Select IPv4 or IPv6 as the internet
protocol type. The internet protocol defines how
data is transferred to and from your device.
• Phone IP address — Enter the IP address of your
device. Select Automatic to have the network
provide the device IP address. This setting is shown
only if you select Network type > IPv4.
• DNS address — Select Primary DNS address and
Secondary DNS address and enter their IP
addresses, if required by your service provider.
Otherwise, the name server addresses are provided
automatically.
• Proxy server address — Enter the address of the
proxy server. Proxy servers are intermediate servers
used by some service providers between a browsing
service and its users. These servers may provide
additional security and speed up access to the
service.
Set up an access point for
WLAN manually
1. Select Menu > Tools > Settings >
Connection > Access points.
2. Select Options > New access point to create a
new access point, or select an existing access point
from the list and then Options > Duplicate access
point to use the access point as a basis for the new
one.
3. Define the following settings.
• Connection name — Enter a descriptive name
for the connection.
• Data bearer — Select Wireless LAN.
• WLAN network name — To enter the service
set identifier (SSID), that is, the name that
identifies the specific WLAN, select Enter
manually. To select the network from the
WLANs in range, select Search for networks.
• Network status — Select Hidden if the network
you are connecting to is hidden or Public if it is
not hidden.
• WLAN network mode — If you select
Infrastructure, devices can communicate with
each other and with wired LAN devices through
a WLAN access point. If you select Ad-hoc,
devices can send and receive data directly with
each other, and no WLAN access point is needed.
• WLAN security mode — You must select the
same security mode that is used in the WLAN
access point. If you select WEP (wired equivalent
privacy), 802.1x, or WPA/WPA2 (Wi-Fi protected
access), you must also configure the relevant
additional settings. See the device help for more
information.
• WLAN security settings — Edit the security
settings for the selected security mode.
