Installing the SmartChip
When you subscribe to a cellular network, you
are provided with a plug-in SmartChip loaded
with your subscription details, such as your
PIN, any optional services available and many
others.
n Important!
The plug-in SmartChip and its contacts can be
easily damaged by scratches or bending, so be
careful when handling, inserting or removing the
card. Keep all SmartChips out of the reach of
small children.
1. If necessary, switch off the phone by
holding down the [END] key until the
power-off image appears.
2. Remove the battery. To do so:
3. Slide the SmartChip into the SmartChip
socket so that it locks the card into place.
Make sure that the notched corner is at the
top left and the gold contacts of the card
face into the phone.
n Note
When you need to remove the SmartChip, slide
it, as shown, and take it out of the socket.
4. Insert the the battery into the battery
compartment as metal contacts meet in the
middle of the phone. Push down the top of
the battery until it snaps into place. Place
the battery cover to the phone as shown.
Getting Started
