Caring for the Battery
1) If you use unauthorized battery, it may cause damage
to or explosion of the battery. Therefore, please do
not use unauthorized ones.
2) You do not need to wait until the battery completely
runs down to recharge the battery.
3) Use only LG batteries and chargers specific to your
model of phone. LG’s chargers are designed to max-
imize battery life.
4) Do not disassemble or short-circuit the battery.
5) Keep the battery’s metal contacts clean.
6) Replace the battery when it no longer provides
acceptable performance. The battery can be
recharged several hundred times before it needs
replacing.
7) Recharge the battery if it has not been used for a long
time to maximize battery life.
8) Do not expose the battery charger to direct sunlight or
use it in areas of high humidity, such as the bathroom.
9) Do not leave the battery in hot or cold places as it
may deteriorate battery performance.
10) Your battery life may vary by location, use patterns,
etc.
11) Long backlight settings, searching for service, data
connectivity, and synchronization all may affect bat-
tery life, talk, and standby times.
Battery Charge Level
The battery charge level is shown at the top right of the
LCD screen.
When the battery charge level becomes low, the low
battery sensor will alert you in three ways: sounding an
audible tone, blinking the battery icon outline, and dis-
playing Recharge battery. If the battery charge level
becomes exceedingly low, the phone will automatically
switch off and any function in progress will not be saved.
Using the Desktop Charger
The desktop holder has a slot to accommodate the
phone with the battery for charging. Warning! Use only
the Desktop charger provided with the phone. Using an
unauthorized charger may cause damage to your
phone or battery.
1) Plug the charger into a wall outlet.
G The phone must be charged from a 240Vac.
power source only.
2) Insert the phone with an installed battery or a battery
into the slot of the charger.
G Red light indicates the battery is being charged.
G Green light indicates the battery is fully charged.
Charge time will vary depending upon battery level.
Maximum charge time for a fully discharged battery will
not exceed 3 hours.
Chapter 1
Getting Started
