NTI RACKMUX RACKMOUNT ANSI TERMINAL DRAWER
50
TECHNICAL SPECIFICATIONS
Physical
Size (In.) WxDxH 19x21.9x1.725
Weight 23.3 lbs.
Temperature 0°~40°C operating, -20°~60°C storage
Humidity 20% to 90% non-condensing
Power Supply (Standard) 110/220VAC, 50-60Hz
Power Supply (RACKMUX-
T15-48V model only)
36-72VDC
Power Consumption 60W (max), <25W (standby)
Cables Included IEC Power cord (country specific), 1-1/2 foot 15HD VGA,6 foot DB9 female to DB25 male null
modem cable
Rack mount kit Included for Sun & most EIA 22-36” racks
LCD Panel Specifications
Screen size 15.1” visible diagonal
Display format 800x600
Controls contrast, brightness, auto-adjust, color temperature
Brightness
250cd/m
2
(Nits)
Contrast 500:1 (typical)
Viewing Angle
140° H / 125° V
Keyboard Specifications
Type 83 key (US) / 84 key (Europe)
Terminal Emulation
Emulations VT52, VT100, VT220, Console ANSI, PC TERM, TVI910+/925, WY-50+, WY-60, WY-100, WY-
120, WY-325, PCG Alpha
Character matrix 7x12 dot matrix in 10x16 cell with 3 dot descenders
Screen size 80x25
Page length 1, 2, or 4 screens (multiple screen page length reduces maximum number of possible telnet
sessions)
Cursor Blink or steady, block or underline
Modes Full duplex, half duplex, block mode, half block mode
Color modes 16 foreground and 16 background colors
Communication Ports
Serial port for host
connection
One DB9M RS232 port
Network port One RJ45 10Base-T Ethernet port
Local printer ports One DB25F Parallel and one DB9M RS232 port
Serial baud rates 50 to 115,200 bps
Data format 7 or 8 data bits with or without parity, 1 or 2 stop bits
Serial handshake XON/XOFF, XPC, and hardware DTR
Communications options Single RS232 server connection, or up to 12 Ethernet telnet sessions to predefined IP addresses.
Both serial and Ethernet connections can not be used concurrently.
