GB 37
Technical specifications
Front panel
2 LEDs, Buttons: , (standby, program number up
and down)
Conditional Access system
Embedded Viacccess. One PCMCIA Interface for each
Common Interface CA-module. DVB standard.
General data
The model code, variant, and serial number are located on
a label on the underside of the receiver.
Restrictions
Bluetooth products are not approved for use
everywhere. Please check with your local
authorities.
The 260 S has a type label on the underside of the
receiver that has the symbol shown below to
indicate that it is equipped with the Bluetooth
connectivity function.
Supply voltage 110-240V AC, 47-63Hz
Power consumption max 20 W at 500mA LNB load
Power consumption in
standby
5 W
Operating temperature +5° C to +45° C
Storage temperature - 40° C to +65° C
Humidity 25 to 90% rel humidity
Operating distance for
remote control
max 10 meters
Dimensions (w x d x h) 250 x 275 x 80 mm
Transmission standards DVB, MPEG 2
LNB/Tuner input
Connector 1x F-type (LNB)
RF input frequency 950-2150 MHz
QPSK
Ku & C-band
SCPC & MCPC
RF input power level -20 to -65 dBm
Supply voltage 13/18 V ±5%
Max. current 500 mA, overload protected
Control voltage 22 kHz, 0.65 V
pp
DiSEqC Tone burst A/B or Level 1.2
RF impedance 75
Ω
TV SCART
Video output 1 V
pp
(1 dB)/75
Audio output 0.5 V
rms
/RL >10
RGB output Internal RGB
RGB bandwidth 5.8 MHz ±3 dB
Fast blanking output Internal or from AUX SCART
Status output 0/6/12 V/ R
L
10 k
AUX SCART
Video output 1 V
pp
(1 dB)/75
Video input 1 V
pp
/75
Audio output 0.5 V
rms
/R
L
>10 k
Audio input 0.5 V
rms
/R
L
>10 k
Status input 0/6/12 V/ R
L
>10 k
DIGITAL AUDIO (S/PDIF)
Connector 1 x RCA
AUDIO R L
Connector 2 x RCA (R+L)
Output 0.5 V
rms
0.5 dB/R
L
10 k
