<td> <img alt="part cldy" src="file://…/partcldy.wbmp"
align="bottom"/> </td>
<td>27°C</td>
</tr>
<tr>
<td>W 6/9</td>
<td> <img alt="cloudy" src="file://…/cloudy.wbmp"
align="bottom"/> </td>
<td>24°C</td>
</tr>
<tr>
<td>T 6/10</td>
<td> <img alt="rainy" src="file://…/rainy.wbmp"
align="bottom"/> </td>
<td>28°C</td>
</tr>
<tr>
<td>F 6/11</td>
<td> <img alt="sunny" src="sunny.wbmp" align="bottom"/> </td>
<td>29°C</td>
</tr>
</table>
Example 2: Table element
4.3 Images
The graphics formats Wireless Bitmap (wbmp), static gif (.gif 87a), and animated gif (.gif 89a)
are supported. The static graphics area is at maximum 78 pixels wide and 30 pixels high, but
vertically and horizontally scrollable until the maximum deck size. However, the animated gif
graphics area is at maximum 78 pixels wide and 30 pixels high. Images fitting in the graphics
area are centered unless specified otherwise by the service provider. Static images that are too
wide are left–aligned and truncated on the right. Images that are too long are top–aligned but
scrollable down.
The displaying of images is optional and can be turned off in the browser appearance settings.
Images can also be used inside a table and as a link (see Example 4.2 above). An image that
functions as a link is represented with a full-line frame around it. Images appear in a separate
line than text.
Figure 2: Image in Nokia 6310
Image sizes of a maximum of one line, that is, 10 pixels high, may be shown with two lines of
text on the same display above and/or below the image. Similarly, with an image of a
maximum of 20 pixels there can be one line of text.. There cannot be text next to an image;
the image will always start its own line.
If a requested image does not exist, a small default picture will be shown. Use of the image alt
attribute value is recommended.
