38 Configuring PAD/ATPAD Ports
PAD Profile Table Record
#103, XON Character
Range: 0 to 255
Default: 17
Description: Specifies the decimal value of the ASCII character used for the
XON function.
#104, XOFF Character
Range: 0 to 255
Default: 19
Description: Specifies the decimal value of the ASCII character used for the
XOFF function.
#105, Control Signal (EIA-232-D) Data Restraint
Range: 0 to 3
Default: 0
Description: Determines how V.24 control signals (instead of XOFF/XON)
flow control the PAD and attached terminal.
Called Out-of-Band flow control; this process applies to data,
commands, and responses to and from the attached device:
• 0: Disabled.
• 1: Data Restraint Outbound (DRO): attached device flow
controls PAD with pin 14 (requires parameter #12 PAD Data
Restraint = 0).
• 2: Data Restraint Inbound (DRI): PAD flow controls attached
device with connector pin 5, CTS (requires parameter #5
Device Flow Control = 0).
• 3: Combination of 1 and 2.
