Configuring PAD/ATPAD Ports 71
ATPAD Ports
What You See in
the Second Screen
Figure 15 illustrates the second screen of Detailed ATPAD Port Statistics.
Figure 15. ATPAD Port Statistics - Screen 2
Data Summary: IN/OUT Summary of the characters, packets, and
frames being sent and received over the port
Interface Summary Summary of the EIA control signals being
sent and received over the port
Possible states are:
• NULL
• Connected (SIMPLE)
• Idle, Connected (DTR), Wait For Clear
(DTR), Wait for DTR (DTR)
• Idle (DTRP), Call Detected (DTRP),
Connected (DTRP)
• Idle, Call Detected (DIMO), Incoming
Call Detected (DIMO), Connected
(DIMO), Clear Confirm (DIMO)
• Idle, RI On (EMRI), RI Off (EMRI),
Wait for RTS (EMRI), Connected
(EMRI), Wait for DTR (EMRI)
Screen Term Tells You...
(continued)
Node: Address: Date: Time:
Detailed ATPAD Port Statistics: Port 3 Page: 2 of 2
Call Summary:
Current Status: Data Transfer
Last clear cause code: 0 (Cleared by other end)
Last clear diagnostic code: 0 (No more information)
Last Inbound Call:
Called Address: 20098
Calling Address: 20003
Facilities:
CUD:
Last Outbound Call:
Called Address:
Calling Address:
Facilities:
CUD:
Press any key to continue (ESC to exit)...
